Uwagi do pamięci RAM: ECC and Non-ECC, Un-buffered Memory, Supports AMD Extended Profiles for Overclocking (EXPO™), OptiMem II, Supported memory types, data rate (speed), and number of DRAM modules vary, depending on the CPU and memory configuration, for more information please, refer to CPU/Memory Support list under the Support tab of product, Non-ECC, un-buffered DDR5 memory supports On-Die ECC function
Zintegrowany kontroler SATA: Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 2x M.2 - RAID 0, 1, 10
Uwagi do kontrolera SATA: Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports, AMD Ryzen™ 7000 Series Desktop Processors, - M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode), AMD B650 Chipset, - M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode), - 4 x SATA 6Gb/s ports, AMD RAIDXpert2 Technology supports both PCIe and SATA 0/1/10 RAID
Wbudowana karta graficzna: Brak lub AMD Radeon™ Graphics (zależy od procesora)
Gniazda karty graficznej: HDMI, VGA, DisplayPort
Uwagi do karty graficznej: Graphics specifications may vary between CPU types. Please refer to AMD C, Supports max. 8K@60Hz as specified in DisplayPort 1.4, Supports 4K@60Hz as specified in HDMI 2.1
Zintegrowana karta dźwiękowa: Realtek ® 7.1 Surround Sound High Definition Audio CODEC
Uwagi do karty dźwiękowej: Jack-detection, Multi-streaming, Front Panel Jack-retasking, Supports up to 24-Bit/192 kHz playback", - Audio Shielding, - Premium audio capacitors, - Dedicated audio PCB layers, A chassis with an HD audio module in the front panel is required to, support 7.1 Surround Sound audio output
Złącza PCI Express x16: 3
Uwagi do złącz PCI: AMD Ryzen™ 7000 Series Desktop Processors:, - 1 x PCIe 4.0 x16 slot (supports x16 mode), AMD B650 Chipset:, - 2 x PCIe 4.0 x16 slots (support x1 mode), To ensure compatibility of the device installed, please refer to
Port LAN: 1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Intel®)
Maksymalna ilość portów USB 2.0: 8
Maksymalna ilość portów USB 3.x: 7
Porty USB na panelu tylnym: 4x USB 2.0 + 2x USB 3.0 + 2x USB 3.1
Gniazda USB na płycie głównej: 2x USB 2.0 (4 porty) + 1x USB 3.0 (2 porty) + 1x USB 3.0 Type-C (1 port)
Port Wi-Fi: IEEE 802.11a/b/g/n/ac/ax
Port Bluetooth: Bluetooth V5.2
Uwagi do WiFi / BT: 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax), Supports 2.4/5GHz frequency band, The Bluetooth version may vary, please refer to the Wi-Fi module, manufacturer's website for the latest specifications
Port PS/2: Port combo klawiatury/myszy PS/2
Port szeregowy (COM): 1x wewnętrzne gniazdo portu COM
Inne porty i gniazda: 3x Addressable Gen 2 header, Clear CMOS header, 4-pin CPU Fan header, 4-pin CPU OPT Fan header, 3x 4-pin Chassis Fan headers, SPI TPM header (14-1pin), AURA RGB header
depending on the CPU and memory configuration, for more information please, ECC and Non-ECC, Un-buffered Memory, Non-ECC, un-buffered DDR5 memory supports On-Die ECC function, OptiMem II, refer to CPU/Memory Support list under the Support tab of product, Supported memory types, data rate (speed), and number of DRAM modules vary, Supports AMD Extended Profiles for Overclocking (EXPO™)
Zintegrowany kontroler SATA:
Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 2x M.2 - RAID 0, 1, 10
Uwagi do kontrolera SATA:
- 4 x SATA 6Gb/s ports, - M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode), - M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode), AMD B650 Chipset :, AMD RAIDXpert2 Technology supports both PCIe and SATA 0/1/10 RAID, AMD Ryzen™ 7000 Series Desktop Processors, Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports
Gniazda karty graficznej:
DisplayPort, HDMI, VGA
Uwagi do karty graficznej:
Graphics specifications may vary between CPU types. Please refer to AMD C, Supports 4K@60Hz as specified in HDMI 2.1, Supports max. 8K@60Hz as specified in DisplayPort 1.4
Zintegrowana karta dźwiękowa:
Realtek ® 7.1 Surround Sound High Definition Audio CODEC
- 1 x PCIe 4.0 x16 slot (supports x16 mode), - 2 x PCIe 4.0 x16 slots (support x1 mode), AMD B650 Chipset :, AMD Ryzen™ 7000 Series Desktop Processors :, To ensure compatibility of the device installed, please refer to
Maksymalna ilość portów USB 2.0:
8
Maksymalna ilość portów USB 3.x:
7
Porty USB na panelu tylnym:
4x USB 2.0 + 2x USB 3.0 + 2x USB 3.1
Gniazda USB na płycie głównej:
2x USB 2.0 (4 porty) + 1x USB 3.0 (2 porty) + 1x USB 3.0 Type-C (1 port)
Port PS/2:
Port combo klawiatury/myszy PS/2
Inne porty i gniazda:
3x 4-pin Chassis Fan headers, 3x Addressable Gen 2 header, 4-pin CPU Fan header, 4-pin CPU OPT Fan header, AURA RGB header, Clear CMOS header, SPI TPM header (14-1pin)
Gniazdo zasilania:
ATX (24-pin) + ATX12V (8-pin) + ATX12V (4-pin)
Uwagi do karty dźwiękowej:
- Audio Shielding, - Dedicated audio PCB layers, - Premium audio capacitors, A chassis with an HD audio module in the front panel is required to, Jack-detection, Multi-streaming, Front Panel Jack-retasking, support 7.1 Surround Sound audio output, Supports up to 24-Bit/192 kHz playback"
Port szeregowy (COM):
1x wewnętrzne gniazdo portu COM
Ilość złącz pamięci DDR5:
4
Uwagi do WiFi / BT:
2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax), manufacturer's website for the latest specifications, Supports 2.4/5GHz frequency band, The Bluetooth version may vary, please refer to the Wi-Fi module
Dane producenta
ASUSTeK Computer Inc.
1F.,No.15,Llde Rd.,Beitou Dist
112 Taipei City
Taiwan
