Uwagi do pamięci RAM: Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and, Extreme Memory Profile (XMP) memory modules, Support up to 96 GB (48 GB single DIMM capacity)
Zintegrowany kontroler SATA: Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 1x M.2 - RAID 0, 1, 10
Uwagi do kontrolera SATA: 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3,, M key, type 2580 SSDs:, - AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs, 4 x SATA 6Gb/s connectors, RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices, RAID 0, RAID 1, and RAID 10 support for SATA storage devices
Wbudowana karta graficzna: Brak lub AMD Radeon™ Graphics (zależy od procesora)
Uwagi do karty graficznej: 1x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz, Support for DisplayPort 1.4 version, 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, Support for HDMI 2.1 version and HDCP 2.3, 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz, Support native HDMI 2.1 TMDS compatible ports, Graphics specifications may vary depending on CPU support, Support for up to 3 displays at the same time
Zintegrowana karta dźwiękowa: Realtek® 8-Channel High Definition Audio CODEC
Uwagi do karty dźwiękowej: You can change the functionality of an audio jack using the audio software, To configure 7.1channel audio, access the audio software for audio settings
Złącza PCI Express x16: 1
Złącza PCI Express x1: 1
Uwagi do złącz PCI: 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:, - AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x16 mode, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode, * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only, one graphics card is to be installed, be sure to install it in the PCIEX16, slot, Chipset:, - 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1(PCIEX1)
Port LAN: 1x 1 Gigabit LAN Realtek®
Uwagi do karty sieciowej: 1 Gbps/100 Mbps/10 Mbps
Maksymalna ilość portów USB 2.0: 8
Maksymalna ilość portów USB 3.x: 4
Porty USB na panelu tylnym: 4x USB 2.0 + 2x USB 3.0
Gniazda USB na płycie głównej: 2x USB 2.0 (4 porty) + 1x USB 3.0 (2 porty)
Port Wi-Fi: Nie
Port Bluetooth: Nie
Port PS/2: Port combo klawiatury/myszy PS/2
Port szeregowy (COM): Brak
Port równoległy (LPT): Brak
Inne porty i gniazda: CPU fan header, 2x system fan headers, Addressable LED strip headers, RGB LED strip header, Front panel header, Front Panel Audio header (AAFP), Gniazdo modułu TPM, Q-Flash Plus button, Clear CMOS jumper
Gniazdo zasilania: ATX (24-pin) + ATX12V (8-pin)
Wymiary [S x W] (mm): 230 x 225
Opakowanie: BOX
Wyposażenie dodatkowe: Norton® Internet Security (OEM version), LAN bandwidth management software
Extreme Memory Profile (XMP) memory modules, Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and, Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support up to 96 GB (48 GB single DIMM capacity)
Zintegrowany kontroler SATA:
Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 1x M.2 - RAID 0, 1, 10
Uwagi do kontrolera SATA:
- AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs, 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3,, 4 x SATA 6Gb/s connectors, M key, type 2580 SSDs:, RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices, RAID 0, RAID 1, and RAID 10 support for SATA storage devices
Gniazda karty graficznej:
D-Sub, DisplayPort, HDMI
Uwagi do karty graficznej:
1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz, 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, 1x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz, Graphics specifications may vary depending on CPU support, Support for DisplayPort 1.4 version, Support for HDMI 2.1 version and HDCP 2.3, Support for up to 3 displays at the same time, Support native HDMI 2.1 TMDS compatible ports
- 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1(PCIEX1), - AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x16 mode, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode, * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only, 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:, Chipset:, one graphics card is to be installed, be sure to install it in the PCIEX16, slot
Uwagi do karty sieciowej:
1 Gbps/100 Mbps/10 Mbps
Maksymalna ilość portów USB 2.0:
8
Maksymalna ilość portów USB 3.x:
4
Porty USB na panelu tylnym:
4x USB 2.0 + 2x USB 3.0
Gniazda USB na płycie głównej:
2x USB 2.0 (4 porty) + 1x USB 3.0 (2 porty)
Port PS/2:
Port combo klawiatury/myszy PS/2
Inne porty i gniazda:
2x system fan headers, Addressable LED strip headers, Clear CMOS jumper, CPU fan header, Front Panel Audio header (AAFP), Front panel header, Gniazdo modułu TPM, Q-Flash Plus button, RGB LED strip header
Gniazdo zasilania:
ATX (24-pin) + ATX12V (8-pin)
Uwagi do karty dźwiękowej:
To configure 7.1channel audio, access the audio software for audio settings, You can change the functionality of an audio jack using the audio software
Port szeregowy (COM):
Brak
Port równoległy (LPT):
Brak
Ilość złącz pamięci DDR5:
2
Dane producenta
Gigabyte Technology Co. Ltd.
NO. 6, BAO CHIANG ROAD
231 Xindian Dist., New Taipei
Taiwan
